malfunction of a record player caused by the use of solid state lubricant
In the world of vintage audio equipment, few pieces are as iconic as the BSR record player. This article will guide you through the process of disassembling, cleaning, and reassembling your 1972-era ITT KP821 record player, ensuring it continues to provide a good listening experience.
**Preparation**
Before you begin, prepare your workspace by ensuring it is clean and well-lit. Gather the necessary tools, including screwdrivers (both small Phillips and flatheads), needle-nose pliers, a soft brush, lint-free cloths, isopropyl alcohol, and a small container for loose parts. Always remember to unplug the player from the mains before starting.
**Disassembly**
The disassembly process involves several steps. Lift the platter (turntable) off the spindle and remove the rubber slipmat. Remove screws from the bottom panel and, if necessary, the top cover. Locate and carefully disconnect the main grounding and audio cables. Identify the SGS TAA621AX1 IC(s) on the amplifier board, which is typically near the phono preamp section.
**Cleaning**
Gently remove dust and debris from the mechanism, platter bearings, and amplifier board using a soft brush. Clean any dirty potentiometers, switches, RCA jacks, and belt pulleys with a damp lint-free cloth. For stubborn grime, cotton swabs can be used carefully around ICs and delicate parts. Wipe the belt with a damp cloth (water only) or replace it if stretched or cracked. Clean rubber idler wheels (if present) with rubbing alcohol.
**Lubrication**
Apply a drop of light machine oil to platter bearings and any other moving parts indicated in the service manual. Do not oil any rubber components.
**Reassembly**
Carefully position the mechanism and board back into place. Reattach the grounding and audio cables, ensuring correct orientation. Slide the rubber mat onto the platter, then carefully place the platter back onto the spindle, ensuring it sits level. Test the turntable for speed stability and audio output before finalizing reassembly.
**Notes on Amplifier ICs**
Avoid unnecessary replacement of parts, especially the SGS TAA621AX1 ICs, unless you have a specific measurement indicating a failed IC or capacitor. Most speed issues are not capacitor-related, and replacing good parts can cause further problems. If in doubt, seek expert assistance to prevent damage and preserve value.
**Best Practices**
Avoid unjustified recapping (replacing capacitors or ICs) and use non-magnetic tools to avoid harming sensitive components. Take photos at each stage to aid reassembly, and take your time, especially with delicate wiring and mechanical linkages.
**Safety**
Some components can hold dangerous charges; allow time for discharge or use a resistor to safely discharge power supply capacitors. Ensure all internal wiring is properly insulated and routed to avoid shorts.
**Conclusion**
Disassembling, cleaning, and reassembling a BSR record player involves careful mechanical work and attention to electronic sensitivity, especially around the SGS TAA621AX1 amplifier ICs. Focus on mechanical cleaning and lubrication, avoid unnecessary electronic part replacement, and always handle the amplifier board with care. If in doubt, seek expert assistance to prevent damage and preserve value.
